Easystand Zing MPS Standing Frame
The Easystand Zing range was designed to fit the widest range of children and accommodate the most complex positioning challenges. The EasyStand Zing Multi-Position Stander (MPS) allows a child to seamlessly go from a full supine to prone position without having to change, turn or flip pads and foot plates or transfer a child in and out of the stander. In one fluid motion, the child can be positioned between supine, upright and prone positions. The ability to make tool-free adjustments and remove support and positioning components adds to the ease of use. The Zing MPS also features 30° of independent leg abduction (60° bilaterally) that is adjustable using a single knob.
More Information
Features
True Multi-Position Stander
The MPS base allows for three positions, without changing pads, flipping footplates or moving the tray. It provides a smooth transition from a flat-to-load transfer to supine, vertical and 20° prone. The frame will only go into supine and upright with the prone position lockout engaged.
True Hip Pivot Leg Abduction
In the Zing, the pivot points are in line with the hips, promoting proper alignment in the hips, knees and feet. The feet maintain the angle with the rest of the legs, and there’s no need for an abduction pad or pommel due to the innovative design. Up to 30° of abduction is available per leg (60° bilaterally).
Plenty of growth
The size 1 Zing MPS fits children from infancy up to 112cm in height and 32kg, while the size 2 fits children up 152cm in height and 70kg. The Zing can easily adapt to changing needs, and many supports, pads and straps are available in multiple sizes for the perfect fit.
Remarkably modular
The Zing MPS can be configured as a simply stander or fit a children with very complex needs. It is designed to grow with the child, and options can be added as needed. It’s great for use in a multi-user facility or school.
Multi-use tray
The Zing MPS features a multi-use tray that is angle adjustable and swings away in either direction. The tray can remain attached during transfers.
Unique lift mechanisms
Dual controls are available, which allow angle adjustment by a foot pedal or hand control. A gas spring lockout prevents an inadvertent change of position, especially important when the stander is being used around other children. The size 2 Zing MPS is also available with a Pow’r Up Lift option, which brings the user up to the standing position with a touch of a button.
Contracture accommodation
No special modifications are needed to accommodate children with contractures. With the multi-adjustable footplates, multi-adjustable knee pads and the independent calf pads, it is possible to adjust for contractures in one or both sides.
Easy adjustment
The Zing MPS features tool-free adjustment of all components. Every adjustment can be made with a simple turn of a knob or ratchet handle.
Hygienic Covers
The Zing covers are available in five fun patterns for the pelvic, upper body, lateral, head and tray areas. The covers help prevent the stander from getting soiled, especially during feedings, and can be easily removed and washed.Technical specifications
| Size 1 | Size 2 | |
|---|---|---|
| Weight limit | 32kg | 70kg |
| Height range | Up to 112cm | 102cm - 152cm |
| Transfer height | 81cm | 79cm |
| Pelvic support to footplate range | 18cm - 56cm | 86cm |
| Upper body support height range | 10cm | 15cm |
| Knee pad depth range | 13cm | 18cm |
| Weight of basic unit | 25kg | 37kg |
| Frame footprint | 51cm x 71cm | 68cm x 110cm |
| Leg abduction | 30° independent leg abduction available | 30° independent leg abduction available |
| Supine | 0° - 90° | 0° - 90° |
| Prone | 0° - 20° | 0° - 20° |
| Positions | Supine | Vertical | Prone | Supine | Vertical | Prone |
| Tray | Adjustable | Swing-away | Adjustable | Swing-away |
| Supports available | Individual positioning components, padded strapping | Individual positioning components, padded strapping |
| Dual control | Available | Available |
| Gas spring lockout | Available | Available |
| Transfer aid | Flat to load | Flat to load |
| Tool free adjustment | Yes | Yes |
| Pow'r Up Lift Option | No | Yes |
Warranty Information
A five year warranty is provided on the Easystand steel frames. A two year warranty is provided on the hydraulic actuator. A 90-day warranty is provided on upholstered components, plastic pads and other components.
Product Compliance with Relevant Standards
Easystand standing frames been tested to and comply with the following standards:
- ISO 13485:2003
- EN ISO 13485:2012
- AAMI ES60601-1
- CAS CSS.2#60601-1
- IEC 60601-1-11
- BS EN 12182:19999
ARTG Certificate: 342931
