Carrot XL Car Seat

The Carrot XL is a larger version of the popular Carrot 3000 car seat, available for older children and adult users who will not fit into the Carrot 3000. The Carrot XL caters for safety and the importance of keeping the user in a supported posture for travel. It comes equipped as standard with the low profile wide seat base, large size headrest, shoulder protector wings, and 50 mm backrest extension. Extendable shoulder protector wings hold and protect the body from side impacts and centrifugal forces.

Tether options for the Carrot XL include an additional security tether for the top of backrest or ISOfix latch connectors. These may be required by your local transport authorities.

Categories: Car seats, Medifab

More Information

Description

Benefits

Wide Low Profile Seat Base

The Carrot XL base is only 6cm thick and 49cm wide to allow for easy access and transfers in and out of a vehicle.

Ergonomic large head support

The Carrot XL’s ergonomic head support holds the user’s head and protects from side impacts and centrifugal forces.

Correct pelvis alignment

Know that your child has the correct postural alignment whilst travelling with a comfort padded hip belt.

Special large harness design

The Carrot XL has a specifically designed harness for older users that supports the shoulders sufficiently and has easy length adjustment.

Upgrade kit from the Carrot 3000 available

The Carrot XL Upgrade kit can be purchased to upgrade an existing Carrot 3000 Car Seat to an XL version, instead of purchasing a whole new car seat when the child grows out of the existing seat. The kit includes:

XL low profile wide seat base
Longer metal rods for base
H-Harness
Hip belt

The XL Upgrade Kit must be fitted by GTK, Medifab Ltd or an authorised Medifab distributor. When upgrading to an XL version the Carrot Shoulder Protector Wings and the 50mm Back Support Infill’s should already been in place. Please note that the upgrade does not include a larger Head Support option.

Available accessories

50mm Back Support Extension: An extension pad to increase the back support height by 50mm.

100mm Back Support Extension: An extension pad to increase the back support height by 100mm.

Trunk Positioning Pads

Air Mesh Cushions in black

Tray Table to support the forearms.

Crotch belt (requires customisation of the seat base)

Pelvis Hip Belts

Tilt wedge to add 20° additional tilt to provide increased head control.

ISOfix latch connectors: when connected to the car seat’s ISOfix, please transport your child with the five-point seat belt of the Carrot and with the three-point seat belt of the car.

Top Tether Strap

Fixing Strap for Aircraft Seat: A horizontal Carrot 3000 fixing attachment strap for securing the Car Seat to an aircraft seat. This is compatible with the Carrot 3000 and the Carrot XL car seats.

MACA and AuSAP

MACA’s Australian Safety Assessment Program (AuSAP) independently assesses the safety and performance of specialty vehicle restraint systems used by children and young people with disabilities and medical conditions. It aims to support and advance safe motor vehicle transport for children and young people with disabilities and medical conditions.

MACA’s Australian Safety Assessment Program (AuSAP) has independently assessed the Carrot XL in accordance with the AuSAP Test and Assessment Protocol. The Carrot XL is published on MACA’s National Product Register. For more information, visit www.macahub.org

Technical specifications

User height	140cm - 175 cm
User weight range	36kg - 75 kg
Seat depth	45 cm
Seat width	48 cm
Shoulder height	45cm - 67 cm (with Shoulder Protector Wings)
Seat weight	10.5 kg
Overall seat depth	46 cm
Overall seat width	52 cm

Warranty Information
The Carrot XL is guaranteed against faulty materials and faulty workmanship for a period of one year.

Product Compliance with Relevant Standards
The Carrot XL has been tested to and complies with the following standards:

ECE R44/04

ARTG Certificate: 151343
