Raz AP600 Attendant Propel Shower Commode Chair
The Raz AP600 mobile shower commode chair features the Multi-Position Back (with centre of gravity adjustment) and comes standard with 4” of height adjustment, an adjustable-tension fabric backrest, 5” dual-locking casters for users up to 181kg and 6″ dual-locking casters for users over 181kg (up to 275kg maximum). It also features flip-up padded armrests, a commode pan, and a large moulded soft foam seat. The electro-polished stainless steel frame is engineered for heavy-duty use and easy access for the user or attendant.
Raz commodes also offer the Ischial and Pelvic Alignment System (IPAS), which provides 2” of seat depth adjustment to accommodate a variety of body sizes and shapes. With a 275kg weight capacity and the many adjustments and options available, the Raz-AP600 will provide maximum comfort and maneuverability for users who require an attendant propelled heavy-duty shower commode chair.
More Information
Standard Features
Moulded seat
The moulded seat is contoured for pressure reduction and pelvic stability. The soft integral-skin foam offers comfort and durability, and the seat is available with open or bridged front.
Ischial Pelvic Alignment System (IPAS)
The Ischial Pelvic Alignment System (see video below) provides 2” (5cm) of fore/aft adjustment so the seat can be aligned with the pelvis. The IPAS allows centering of the aperture (opening) around the user’s ischial tuber-sixties. The seat locks in place for transfers and removes easily for cleaning. Optional spacers are available for anterior or posterior seat angle adjustment.
Adjustable footplates
The footrests are removable for transfers and cleaning. The footrests swing in and out easily and the flip-up footplate moves easily out of the way when needed. You can adjust for leg length without tools, with the footrest available in regular length of 16″ to 20½” (40cm to 52cm) and extended length 18″ to 22½” (46cm to 57cm).
Telescoping Caster Extensions
The caster extensions provide 4″ (10cm) of seat height adjustment without the need to use any tools. The dropped front frame tube also improves access over standard toilet bowls.
Tension-Adjustable Back
The Tension-Adjustable Back is constructed with vinyl coated fabric for durability, comfort and improved infection control. Adjusting the tension to suit the individual user provides individualised trunk support for optimal positioning and comfort. The back is removable for machine washing and is available in 20″ back height.
Commode pan
The injection-moulded pan is designed for function and includes a lid for splash and odour control. The wide handle angled at 45 degrees provides better ergonomics, while the sloped front of pan moves contents toward the handle to reduce offset load, thereby making it easier to carry. Receiver brackets under the seat are visible from the rear of the chair, making it easier to slide the pan into place. The pan fits in a standard autoclave for sterilisation.
Available options and accessories
Previous
Next
Technical specifications
| Weight capacity | 275kg |
| Seat width (seat and back frame) | 56cm (22") - 76cm (30") |
| Overall width (with standard armpad) | 67cm (26.5") |
| Seat width (commode seat) | 58cm (23") |
| Seat depth (front of back post to front of seat) | 46cm (18") |
| Overall length (with Z709 footrests) | 91cm - 99cm (36" - 39") |
| Clearance height under seat | 5" castors with pan brackets: 36cm - 46cm (14.25" - 18.25") 5" castors without pan brackets: 38cm - 48cm (15" - 19") 6" castors with pan brackets: 39cm - 49cm (15.25" - 19.25") 6" castors without pan brackets: 41cm - 51cm (16" - 20") |
| Armrest height above seat | 24cm (9.5") |
| Seat to floor height | 48cm - 58cm (19" - 23") in 1" increments |
| Product weight | 5" castors: 25kg 6" castors: 26.7kg |
| Frame and hardware material | Stainless steel |
Warranty Information
A two-year limited warranty covers the frame against manufacturing defects. A one-year limited warranty covers all other components, subject to normal wear and tear exclusions.
Product Compliance with Relevant Standards
The Raz AP-600 is currently undergoing testing for product compliance.
ARTG Certificate: 169562
